Chinese Medicine Tablet Belt Dryer

The drying method of Chinese medicine tablets is directly related to the quality of the tablets, used to use the sun room drying both in line with the certification requirements and can reduce costs, but at present a small number of enterprises in the sun room design is not reasonable, first, the area is small, can not meet the production requirements. Secondly, the facilities of the sun room are not well equipped, only with dustproof function, without supporting ventilation, dehumidification, ground frame and other devices, and the drying speed is slow. According to the characteristics of Chinese medicine tablets, our company designs the belt dryer which meets the requirements of Chinese medicine tablets, and utilizes the belt dryer equipment to dry the tablets, which is not affected by the climate, and is more hygienic than the natural drying and can shorten the drying time, and can be used for mass production.

Chinese medicine tablets belt dryer equipment overview

Chinese medicine tablets belt dryer consists of feeding system, fabric system, air inlet filtration system, heating and cooling system, main machine, transmission system, bypass filtration system, discharging system, exhaust and moisture removal system, control system and so on. When working, from the feed system to the fabric system, the material will be added to the belt dryer, the material and through the mesh belt through the flow of hot air, cold air encounter, heat transfer, mass transfer, hot air recycling so that lower energy consumption, up to a certain humidity, part of the mandatory dehumidification to take away the moisture, the material to complete the drying and cooling.

Chinese medicine tablets belt dryer equipment features

1, hot air inlet temperature through the ratio adjustment valve display control, so as to control the inlet temperature within the set range.

2、The speed of mesh belt is adjustable by frequency conversion, which ensures the residence time of materials and the quality of discharged materials.

3、Drive motor, stirring motor, moisture exhaust fan frequency adjustable.

4、The bottom of the bottom mesh belt of the belt machine is made into a slanting surface, so as to collect and clean the materials.

5、After the equipment is made, the transmission and conveying system is test run without abnormal sound and jamming.

6、Ultrasonic material level detector is set on the bin with mixing to ensure reasonable material level and linkage with the front conveying line to make the production line smoother.

7、The doors of each part of the box are well insulated, sealed and easy to open and close.

8、Each unit is equipped with cleaning access door on both sides, which can directly rinse the inside of the equipment.

Chinese medicine tablets belt dryer applicable materials

Chinese medicine tablets dryer can dry most of the Chinese herbal medicines through the temperature and speed of the equipment parameters, flakes, powder and other Chinese herbal medicines can be dried almost all the time.
